The production capacity of DHL600 High-Speed Blister-Cartoning Link Machine can reach 600 blisters/min and 300 cartons/min,suitable for mass production.The whole production line with the concept of advanced technology,original create link machine (1-5) blister cartoning production new pattern,can complete switchover (1-5) blister cartoning within one minute,high speed transferred by intelligent flex picker,complete blister cartoning; Leaflet folder can accomplish 300 pages/min (A4 paper).
DPP250FII-XWZ120 Main Technical Parameter
|
Main Technical Parameter |
|||
|
Capacity(cycle/min) |
20-40 |
||
|
Packing material |
Range of stroke(mm) |
40-120 |
|
|
Pharmacy PVC(mm) |
(0.2-0.5)×250 |
||
|
PTP alu foil(mm) |
(0.02-0.05)×250 |
||
|
Tropical alu(mm) |
(0.09-0.15)×250 |
||
|
Clean compressed air(pressure) |
0.5～0.7Mpa |
||
|
Air consumption( m3/min) |
≥0.3 |
||
|
Power |
AC380V 50HZ 12KW |
||
|
Water chiller for moulds |
Tap water or recycle water with 60L/h consumption |
||
|
Overall dimension(L×W×H) |
4890x650x1700 |
||
|
Net weight |
2600 |
||
|
Main Technical Parameter |
|||
|
Capacity (Cartons/min) |
30-80 |
||
|
Packing material |
Box dimension(L×W×H) |
(75-180)×(80-120)×(15-65) |
|
|
Cardboard of box required |
280-350 |
||
|
Leaflet dimension(L×W) |
(90-260)×(90-180) |
||
|
Leaflet paper required |
50-70 |
||
|
Clean compressed air(pressure) |
0.5～0.7Mpa |
||
|
Air consumption( m3/min) |
≥0.3 |
||
|
Power |
AC220V 50HZ 1KW |
||
|
Overall dimension(L×W×H) |
3650×1240×1610 |
||
|
Net Weight |
1700 |
||
