1.Worm wheel Reductor:Main machine overloading protect with lower noise and stabile running.
2.Adjustable range of stroke: Can change the stroke dimension freely to suitable more kinds of product.
3.0nline mechanical photography detection and rejection device with rejected rate(option).
4.Double orientation shafts with spline shaft transmission adopted to ensure synchronization stabile running.
5.Touch screen with PLC mould adopted,stabile operation and easy maintenance (option).
DPP250S Main Technical Parameter
|
Main Technical Parameter |
||
|
Capacity(Cycle/min) |
AL/PL≤50,AL/AL≤35 |
|
|
Range of stroke(mm) |
40-120 |
|
|
Packing material |
Pharmacy PVC(mm) |
(0.2-0.5)×250 |
| PTP alu foil(mm) | (0.02-0.05)×250 | |
| Tropical alu(mm) | (0.09-0.15)×250 | |
|
Clean compressed air(pressure) |
0.5～0.7Mpa |
|
|
Air consumption(m3min) |
≥0.3 |
|
|
Power |
AC380V 50HZ 9 KW |
|
|
Water chiller for moulds |
Tap water or recycle water with 60l-/h consumption |
|
|
Overall dimension(L×W×H)(mm) |
3890×650×1650 |
|
|
Net weight(kg) |
1800 |
|
